Using Android Navigation Deeplink: An Easy Way to Use Deep Link in Navigation Component on a Big Project

Navigation on Android is now easier than ever before with the Jetpack Navigation Component. This library allows you to implement navigation without the headache of complex navigation, which makes it easier to scale your navigation implementation in large projects.

Navigation Component Benefits
1. Automates fragment transactions, this can make our code cleaner.
2. Handles back stack
2. Simplified deep linking
3. Safe Args allows you to pass data between screens easily and type-safe
4. Handles transition animations
5. We can handle Drawer and Bottom Navigation easier
6. Centralizes and visualizes navigation

In this article, I will show you my experience and some problems you might found when you use Jetpack Navigation Component in a big project.

Don't reuse fragments in many navigation graphs.
In a big project, you can't avoid reusing a fragment in many Navigation graphs, but you might end up with this error:

The error happens when you try to release the project with pro-guards because SafeArgs Plugin will generate classes ****Args.kt and ***Directions.kt for all navigation graphs, but pro-guards won't allow you to have duplicate classes.

The solution, Nested Graph!
When you need to use a fragment in many flows you can create a nested graph and reuse it anywhere.

Deep-link is the hero!
You can't predict the future requirements of the business, but you can prepare for future change, deep-link in navigation component can make a complicated flow much simpler.

At the beginning of the project, you may have a significantly complicated flow, However, one day the requirements change, and now the app needs to use just a small flow from the significant flow. We could easily copy some part of the flow into the new flow, but we would have duplicate code.

The solution is to make the flow smaller using the nested graph as I mentioned before and use the deep link for navigations.

Global Action
Global action is one way to access your navigation graphs from everywhere even from a nested graph just like a deep link, however they can't be accessed from another application.

---

Creating deep links
Here is a shopping cart project which has a product listing, shopping cart, payment, history, and more, and the project is also modularized by feature and uses Single Activity Architecture. I am assuming you already know how to set up and create basic navigation graphs. If you don't, you can learn by following Google's code lab.

When you create a navigation graph, I recommend creating one deep link for one flow where you can access the flow from anywhere in the project. Then, use the deep link for navigating between pages in your app, as you might need deep links in the future.

Create a Listing graph

<?xml version="1.0" encoding="utf-8"?>
<navigation xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/navigation_listing"
    app:startDestination="@id/listingFragment">

    <fragment
        android:id="@+id/listingFragment"
        android:name="com.him.oozoublog.navcom.listing.ui.listing.ListingFragment"
        android:label="fragment_listing"
        tools:layout="@layout/fragment_listing">
        <deepLink
            android:id="@+id/deepLink"
            app:uri="myapp://listing" />
    </fragment>
    ......
</navigation>

<?xml version="1.0" encoding="utf-8"?>
<navigation xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:id="@+id/navigation_shopping_cart"
    app:startDestination="@id/shoppingCartFragment">

    <fragment
        android:id="@+id/shoppingCartFragment"
        android:name="com.him.oozoublog.navcom.shoppingcart.ui.ShoppingCartFragment"
        android:label="ShoppingCartFragment">
        <deepLink
            android:id="@+id/deepLink"
            app:uri="myapp://shopping-cart" />
    </fragment>
</navigation>

<?xml version="1.0" encoding="utf-8"?>
<navigation xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:id="@+id/history_navigation"
    app:startDestination="@id/historyFragment">

    <fragment
        android:id="@+id/historyFragment"
        android:name="com.him.oozoublog.navcom.history.ui.HistoryFragment"
        android:label="HistoryFragment">
        <deepLink
            android:id="@+id/deepLink"
            app:uri="myapp://history" />
    </fragment>
</navigation>

<?xml version="1.0" encoding="utf-8"?>
<navigation xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:id="@+id/navigation_payment"
    app:startDestination="@id/paymentFragment">

    <fragment
        android:id="@+id/paymentFragment"
        android:name="com.him.oozoublog.navcom.payment.ui.PaymentFragment"
        android:label="PaymentFragment">
        <deepLink
            android:id="@+id/deepLink"
            app:uri="myapp://payment" />
    </fragment>
</navigation>

<?xml version="1.0" encoding="utf-8"?>
<navigation xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:id="@+id/main_navigation"
    app:startDestination="@+id/navigation_listing">

    <include app:graph="@navigation/navigation_listing" />

    <include app:graph="@navigation/navigation_history" />

    <include app:graph="@navigation/navigation_shopping_cart" />

    <include app:graph="@navigation/navigation_payment" />

</navigation>

object InternalDeepLink {
    const val DOMAIN = "myapp://"

    const val LISTING = "${DOMAIN}listing"
    const val PAYMENT = "${DOMAIN}payment"
    const val SHOPPING_CART = "${DOMAIN}shopping-cart"
    const val HISTORY = "${DOMAIN}history"

    fun makeCustomDeepLink(id: String): String {
        return "${DOMAIN}customDeepLink?id=${id}"
    }
}

listingViewModel._navigateToShoppingCart.observe(viewLifecycleOwner, {
    val deepLink = InternalDeepLink.SHOPPING_CART.toUri()
    findNavController().navigate(deepLink)
})

enum class SearchType {
    ALL,
    CAR,
    WATCH
}

<?xml version="1.0" encoding="utf-8"?>
<navigation xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:id="@+id/navigation_listing"
    app:startDestination="@id/listingFragment">

    <fragment
        android:id="@+id/listingFragment"
        android:name="com.him.oozoublog.navcom.listing.ui.listing.ListingFragment"
        android:label="fragment_listing"
        tools:layout="@layout/fragment_listing">
        <argument
            android:name="searchType"
            android:defaultValue="ALL"
            app:argType="com.him.oozoublog.navcom.listing.ui.listing.SearchType" />
        <deepLink
            android:id="@+id/deepLink"
            app:uri="myapp://listing?searchType={searchType}" />
    </fragment>
</navigation>

How to get the data from deep links.
When we navigate to another page with some data SafeArgs Plugin will automatically handle the data. When you rebuild the project you will see ListingFragmentArgs.kt. This plugin also converts the data to your custom class if there is any.

You can use navArgs() delegate for passing data like this:

class ListingFragment : Fragment() {
    ....
    private val args: ListingFragmentArgs by navArgs()

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        Log.i("search type", args.searchType.name)
    }
    ....
}

Introduction to Deep Links

Setting Up the Navigation Component

dependencies { implementation 'androidx.navigation:navigation-fragment:2.3.5' implementation 'androidx.navigation:navigation-ui:2.3.5' }

Creating and Handling Deep Link

@Override protected void onNewIntent(Intent intent) { super.onNewIntent(intent); Navigation.findNavController(this, R.id.nav_host_fragment).handleDeepLink(intent); }

Best Practices for the Navigation Component

• Use a Single Navigation Graph: Maintain a single navigation graph for your entire app to centralize navigation logic and simplify management.
• Prefer Fragments Over Activities: Use fragments as destinations instead of activities to leverage the benefits of the Navigation Component.
• Utilize NavController: Navigate between destinations using the NavController to ensure consistent and predictable navigation behavior.
• Leverage NavigationUI: Use NavigationUI to handle navigation-related UI elements, such as the navigation drawer and bottom navigation.
• Thoroughly Test Your Navigation Graph: Regularly test your navigation graph to ensure it functions as expected and provides a seamless user experience.

Testing and Troubleshooting Deep Links
